void min_heap_ctor_(min_heap_t* s) { s->p = 0; s->n = 0; s->a = 0; }			//构造(初始化)一个最小堆
void min_heap_dtor_(min_heap_t* s) { if (s->p) mm_free(s->p); }				//析构(释放)一个最小堆
void min_heap_elem_init_(struct event* e) { e->ev_timeout_pos.min_heap_idx = -1; }	//初始化最小堆的成员变量
int min_heap_empty_(min_heap_t* s) { return 0u == s->n; }				//判断最小堆是否为空
unsigned min_heap_size_(min_heap_t* s) { return s->n; }					//获取最小堆的大小
struct event* min_heap_top_(min_heap_t* s) { return s->n ? *s->p : 0; }			//获取最小堆的根结点

/** Return true iff the tvp is related to uvp according to the relational
 * operator cmp.  Recognized values for cmp are ==, <=, <, >=, and >. */
#define	evutil_timercmp(tvp, uvp, cmp)					\
	(((tvp)->tv_sec == (uvp)->tv_sec) ?				\
	 ((tvp)->tv_usec cmp (uvp)->tv_usec) :				\
	 ((tvp)->tv_sec cmp (uvp)->tv_sec))

#define min_heap_elem_greater(a, b) \
	(evutil_timercmp(&(a)->ev_timeout, &(b)->ev_timeout, >))

//这个函数的作用是根据n决定是否重新分配最小堆数组的大小
int min_heap_reserve_(min_heap_t* s, unsigned n)
{
	//如果数组的容量还够，直接返回
	if (s->a < n)
	{
		struct event** p;
		//如果最小堆数组的大小不为0，则重新动态分配的大小为原先大小的2倍
		//否则，只分配数组大小为8
		unsigned a = s->a ? s->a * 2 : 8;
		//调用分配算法之后，还是不够，需要在作调整
		if (a < n)
			a = n;
		if (!(p = (struct event**)mm_realloc(s->p, a * sizeof *p)))
			return -1;
		s->p = p;	//重新分配之后最小堆的数组
		s->a = a;	//重新分配之后最小堆的大小
	}
	return 0;
}

//将某个叶子结点的堆元素上浮到合适的位置，用于堆元素的插入
void min_heap_shift_up_(min_heap_t* s, unsigned hole_index, struct event* e)
{
    unsigned parent = (hole_index - 1) / 2;	//根据最小堆中堆元素的个数，计算出要插入节点e的父结点的下标
    //如果hole_index等于0，也就是说最小堆为空，那么就不会进入while，e就是根结点了
    //否则，e就与其父节点比较
    while (hole_index && min_heap_elem_greater(s->p[parent], e))
    {
	//如果父节点大于e，显然是不符合最小堆的定义，那么就移动父节点到新的下标上
	//仅紧接着看e是否能放到原先父节点的位置上，其实就是继续和父节点比较
	(s->p[hole_index] = s->p[parent])->ev_timeout_pos.min_heap_idx = hole_index;
	hole_index = parent;
	parent = (hole_index - 1) / 2;
    }
    //已经找到适合放置e了
    (s->p[hole_index] = e)->ev_timeout_pos.min_heap_idx = hole_index;
}





//将某个叶子结点的堆元素下浮到合适的位置，用于堆元素的取出
void min_heap_shift_down_(min_heap_t* s, unsigned hole_index, struct event* e)
{
    unsigned min_child = 2 * (hole_index + 1);	//下标为hole_index的右孩子的下标
   //如果对应的hole_index左右孩子，那么取出hole_index就简单了
    while (min_child <= s->n)
	{
	//根据运算符的优先级，我们可以知道表达式(min_child == s->n)先计算，
	//该 表达式为真表示hole_index仅有左孩子，也就不会再计算后面表达的值。
	//否则，就以看右孩子是否大于左孩子，如果是整个表达式为真（1）
	//那么整个表达式就很清晰了：用于计算hole_index左右子结点最小的那个
	min_child -= ((min_child == s->n) || min_heap_elem_greater(s->p[min_child], s->p[min_child - 1]));
	if (!(min_heap_elem_greater(e, s->p[min_child])))
	    break;	//把e放到hole_index下标能符合最小堆的定义，就不需要下浮了
	//否则，把左右子结点中最小的放入hole_index下标的位置，然后继续看空出的位置是否能
	//放入e满足最小堆的定义，不行就进行 下浮。
	(s->p[hole_index] = s->p[min_child])->ev_timeout_pos.min_heap_idx = hole_index;
	hole_index = min_child;
	min_child = 2 * (hole_index + 1);
	}
    (s->p[hole_index] = e)->ev_timeout_pos.min_heap_idx = hole_index;
}
//和min_heap_shift_up_类似，只是一次无条件上浮
void min_heap_shift_up_unconditional_(min_heap_t* s, unsigned hole_index, struct event* e)
{
    unsigned parent = (hole_index - 1) / 2;
    do
    {
	(s->p[hole_index] = s->p[parent])->ev_timeout_pos.min_heap_idx = hole_index;
	hole_index = parent;
	parent = (hole_index - 1) / 2;
    } while (hole_index && min_heap_elem_greater(s->p[parent], e));
    (s->p[hole_index] = e)->ev_timeout_pos.min_heap_idx = hole_index;
}

2.2 min_heap_push_

//向最小堆中插入一个对元素
int min_heap_push_(min_heap_t* s, struct event* e)
{
	//最小堆空间是否足够，不够则进行分配
	if (min_heap_reserve_(s, s->n + 1))
		return -1;
	//将要放入的最小堆的堆元素放到，最小堆数组的最后面，然后上浮到对应的位置
	min_heap_shift_up_(s, s->n++, e);
	return 0;
}

2.3 min_heap_pop_

//取出最小堆的根结点
struct event* min_heap_pop_(min_heap_t* s)
{
	//最小堆为空，则返回MILL
	if (s->n)
	{
		struct event* e = *s->p;	//取出最小堆的根结点
		//将最小堆最后的堆元素放入到根结点的位置并进行下浮
		min_heap_shift_down_(s, 0u, s->p[--s->n]);
		e->ev_timeout_pos.min_heap_idx = -1;
		return e;
	}
	return 0;
}

2.4 min_heap_elt_is_top_

//判断某个堆元素是否是跟结点
int min_heap_elt_is_top_(const struct event *e)
{
	return e->ev_timeout_pos.min_heap_idx == 0;
}

2.5 min_heap_erase_

//在最小堆中销毁e，并用堆的最后一个堆元素进行替换和调整
int min_heap_erase_(min_heap_t* s, struct event* e)
{
	if (-1 != e->ev_timeout_pos.min_heap_idx)
	{
		struct event *last = s->p[--s->n];	//取出最后一个堆元素
		unsigned parent = (e->ev_timeout_pos.min_heap_idx - 1) / 2;	//e的父结点
		/* we replace e with the last element in the heap.  We might need to
		   shift it upward if it is less than its parent, or downward if it is
		   greater than one or both its children. Since the children are known
		   to be less than the parent, it can't need to shift both up and
		   down. */
		//如果e不是根结点，并且准备销毁的结点的父节点比最后一个堆元素大（不符合最小堆），那么
		//就进行上浮（用于无条件上浮，确保被销毁），否则就需要下浮
		if (e->ev_timeout_pos.min_heap_idx > 0 && min_heap_elem_greater(s->p[parent], last))
			min_heap_shift_up_unconditional_(s, e->ev_timeout_pos.min_heap_idx, last);
		else
			min_heap_shift_down_(s, e->ev_timeout_pos.min_heap_idx, last);
		e->ev_timeout_pos.min_heap_idx = -1;
		return 0;
	}
	return -1;
}

2.6 min_heap_adjust_

//调整e在最下堆的位置，e可能是堆中原本的堆元素或不是堆元素
int min_heap_adjust_(min_heap_t *s, struct event *e)
{
	if (-1 == e->ev_timeout_pos.min_heap_idx) {
		//如果e不是堆元素，则直接添加到堆中去
		return min_heap_push_(s, e);
	} else {
		//否则就看e是否符合最小堆，不符合就需要进行上浮或下浮操作
		unsigned parent = (e->ev_timeout_pos.min_heap_idx - 1) / 2;
		/* The position of e has changed; we shift it up or down
		 * as needed.  We can't need to do both. */
		if (e->ev_timeout_pos.min_heap_idx > 0 && min_heap_elem_greater(s->p[parent], e))
			min_heap_shift_up_unconditional_(s, e->ev_timeout_pos.min_heap_idx, e);
		else
			min_heap_shift_down_(s, e->ev_timeout_pos.min_heap_idx, e);
		return 0;
	}
}

//重新分配最小堆的大小（整个最小堆数组的大小）
int min_heap_reserve_(min_heap_t* s, unsigned n)
{
	if (s->a < n)
	{
		struct event** p;
		unsigned a = s->a ? s->a * 2 : 8;
		if (a < n)
			a = n;
		if (!(p = (struct event**)mm_realloc(s->p, a * sizeof *p)))
			return -1;
		s->p = p;
		s->a = a;
	}
	return 0;
}
